Sample: 3-Tier Network with Firewall & VSS
Demo mode · Fixed topology
🔒

Demo mode — Fixed sample topology

This demo uses a pre-configured 8-device sample topology. Device editing is disabled. Create a Free account to customize these devices and generate your own workbook.

Sample: 3-Tier Network with Firewall & VSS

✓ 8 devices configured✓ 3 network tiers configured✓ Connections completed
Tier 1— Internet Edge (Firewalls)
fw01
Checkpoint FW
fw02
Checkpoint FW
Tier 2— Core (VSS Pair)VSS Pair
core01VSS
Cisco C9500 Core
core02VSS
Cisco C9500 Core
Tier 3— Servers
server01
Dell Server
server02
Dell Server
server03
Dell Server
server04
Dell Server

Topology Notes

  • Firewalls (fw01, fw02) are physical devices — not a logical pair in Unravlr terms
  • Core switches (core01, core02) form a VSS logical pair
  • Servers (server01–04) are dual-homed to both core switches
  • No Out-of-Band management tier in this sample
